New areas of application are possible
Magnet withstands extreme stresses

Bilfinger’s super-conducting magnet withstands extreme stresses
Picture: Bilfinger

Bilfinger has succeeded in making super-conducting technology deployable under the harshest ambient conditions, for example in an industrial environment. Its so-called strip conductors can be operated at higher temperatures than the conventional round, low-temperature super-conductors, and their component materials also feature different characteristics. Bilfinger put these advantages to use and made the new magnet more resilient. Moreover, while traditional magnet systems frequently deploy liquid gases, making operations complex and expensive, Bilfinger’s system applies the more user-friendly “cryo-cooler” technology and entirely dispenses with liquid gases.

Dr. Ronald Hepper, managing director of Bilfinger Noell: “By refining magnet technology in this ways, we have reached a milestone. We have proven that our super-conducting magnets can be deployed under the toughest ambient conditions, such as in the domains of industry, transport and logistics as well as in aviation, aerospace or maritime shipping.”

Its subsidiary Bilfinger Noell conceived the modern high-temperature super-conducting magnet. As part of several measurement campaigns, the technology was mounted in a special shock-testing rig and was exposed to multidirectional stressor forces up to 14 times more powerful than gravitational acceleration. Initially, the resilience of subcomponents was established, after which the entire system was exposed to the stresses in a second test run while in operating mode. Despite being subjected to the enormous dynamic loads of up to 14 G, which were directed either horizontally or vertically onto the magnet array, the system continued operating smoothly. Even at maximum load, there were no disruptions and the set-up was able to maintain the super-conducting status of the magnetic field.

Super-conducting applications are used primarily in medical engineering and research; the technology allows magnetic fields to be generated in a compact and efficient manner. For several years now, Bilfinger has been working together successfully on various projects with scientific institutions such as the Karlsruhe Institute of Technology, Cern or GSI Helmholtzzentrum für Schwerionenforschung (Helmholtz Center for Heavy Ion Research).

Bilfinger Noell, based in Würzburg, Germany, is a group company of Bilfinger SE. It offers customized solutions to customers worldwide while also building high-tech special-purpose machinery. Bilfinger Noell’s range of services includes the development, planning, delivery and commissioning of plants and their facilities as well as their operational management. The 270 employees on staff work mainly in the engineering field.

Chemicals News

Marl Chemical Park
Siemens build industrial power plant

Published

on

Siemens to build industrial power plant at the Marl Chemical Park in Germany
Picture: Siemens

Siemens will build a highly efficient combined cycle power plant as a turnkey project at the Marl Chemical Park in North Rhine-Westphalia, Germany. The order was placed by the specialty chemical group Evonik Industries. The new industrial power plant will consist of two units, each with an electrical capacity of 90 megawatts, and produce both electricity and process steam for the chemical park. The site’s integrated steam network will also supply district heat for about 2,000 homes in the future. The plant’s fuel efficiency will thus exceed 90 percent. With this combined cycle power plant, Evonik will replace its last coal-fired plant at the Marl Chemical Park. Because the plant will produce environmentally friendly electricity, process steam, and district heat from natural gas, the company will be able to cut CO2 emissions by one million metric tons per year. The plant thus makes an important contribution to decarbonization. Construction is scheduled to begin later in 2019, and the power plant is expected to go into operation in 2022. Siemens Financial Services (SFS), Siemens’ financing arm, developed a leasing financing solution specifically for Evonik in collaboration with Siemens Gas and Power. Together with the KfW IPEX Bank and LBBW, SFS will handle refinancing of the leasing agreement. The project volume is in the lower triple-digit million euro range.

“In building this power plant, whose technical and commercial concept was worked out jointly between Siemens and Evonik, we’re helping Evonik significantly cut its CO2 emissions,” said Michael Becker, CFO of Siemens Gas and Power. “In addition, the state-of-the-art plant will ensure a reliable supply of electricity and process steam for the chemical park. The ability to use various gases as fuel is another benefit and further increases the plant’s economic feasibility.”

“In deciding to build the new power plant, we’re ending our coal-based production of electricity and steam in Marl after more than 80 years, and cutting the direct annual greenhouse gas emissions of our plants by nearly one fifth worldwide,” said Thomas Wessel, Chief Human Resources Officer at Evonik. “We are pleased to have Siemens at our side, a reliable partner who is helping us to achieve our ambitious climate goals.”

“Siemens Financial Services’ structuring expertise and experience in the energy sector for years enabled us to offer a financing solution tailored to the customer’s needs,” said Veronika Bienert, CFO of Siemens Financial Services. “This made it possible to implement the project in close cooperation with Siemens Gas and Power, which is providing the technology and service activities.”

Siemens’ scope of supply includes the turnkey construction of two identical power plant units as well as one industrial gas turbine, and one industrial steam turbine for each unit. It also includes generators, auxiliary systems, and the control system.

Siemens will carry out preventive maintenance work on both gas turbines for a period of 15 years under a long-term service agreement. This agreement also covers remote diagnostic services for daily plant monitoring and monthly analyses of the operating data. These digital services will ensure high plant availability.

Thanks to the use of special heat recovery steam generators and catalysts, the system can operate on natural gas as well as re-gasified liquefied natural gas (LNG), and various other gases, such as residual gas from production processes. Each power plant unit can produce not only electricity but also up to 220 metric tons of process steam per hour. Thanks to the plant’s high flexibility that enables it to compensate for the fluctuating infeed of renewable energy into the power grid and its ability to produce district heat, it is also supporting the energy transition in Germany.

Continue Reading

Chemicals Fairs Food & Beverage Pharmaceuticals Plant Construction, Engineering & Components

For the polymers, chemical, pharma and food industry
Next Generation of High Accuracy Vibratory Feeding Technology

Published

on

Coperion K-Tron’s new line of K3 vibratory feeders features a unique, patent-pending drive system combined with an advanced control package, resulting in gentler product handling, higher accuracy and quicker product changeover. (Picture: Coperion K-Tron)
Coperion K-Tron’s new line of K3 vibratory feeders features a unique, patent-pending drive system combined with an advanced control package, resulting in gentler product handling, higher accuracy and quicker product changeover. (Picture: Coperion K-Tron)

Coperion K-Tron is proud to announce a completely new K3 line of vibratory feeders for dry bulk solids.  The innovative new feeder design features a unique, patent-pending drive system combined with an advanced control package.  The new K3 vibratory feeder is able to achieve accuracies averaging 35% better over traditional vibratory technologies. This revolutionary new generation of Coperion K-Tron loss-in-weight vibratory feeders offers gentle handling of the bulk material, higher accuracy and faster product changeover, resulting in less product waste, less downtime and better end product quality as well as improved sustainability.

New technology brings significant advantages

These advantages are possible thanks to groundbreaking new technology. The key to achieving high accuracy is the ability to deliver a continuous, even product discharge with minimal pulsations. The new K3 vibratory drive is able to do this thanks to a completely new shock absorber design. Conventional vibratory feeders use rubber or spring shock absorbers, which allow movement of the drive in all directions, resulting in rotational motion. In contrast to these conventional shock absorbers, the new K3 line uses a unique flexible pendulum technology which provides shock absorption only parallel to the desired direction of motion, eliminating rotational movement. This parallel motion ensures an even material flow of the product along the entire length of the tray.

The advanced control system and feeder electronics include internal sensors which measure acceleration, displacement, load, current and temperature at rates of up to 25,000 times per second. The fast-acting controller then adjusts the vibratory drive signal to maintain clean sinusoidal displacement for optimal mass flow. The combination of this unique drive with the Coperion K-Tron SmartConnex control system also results in extremely low energy consumption as compared to other feeding technologies. Power consumption can be as low as 20 Watts for feed rates as high as 6,000 kg/h, thus making it ideal for improved production sustainability and minimal heat dissipation.

The typical feeder package consists of a feed hopper, vibratory tray and vibratory drive mounted on a weighing system featuring patented, high accuracy Smart Force Transducer weighing technology and combined with SmartConnex controls. The mechanical package is modular in design, and versatile in that it can accommodate custom tray configurations and lengths, offering the user more flexibility.  A special quick-release clamp mechanism on the feeder tray allows for quick product changeover. The absence of mechanical wear parts results in lower maintenance requirements and ensures gentle handling of the bulk material. In addition to the standard design, a line of hygienic, easy-clean configurations is also available. These include a hygienic silicone cover to enclose the complete drive assembly, making it also suitable for food and pharmaceutical applications.

Ideal for gentle handling of difficult bulk materials

Vibratory feeders are ideal for the gentle handling of a wide variety of materials, including friable products, abrasive products, products with non-uniform shapes, and glass fibers. They are ideally suited to applications such as the high accuracy feeding of finished food products to packaging lines, uncoated tablets to coating lines, as well as difficult feeding of pellets or regrind to plastic extrusion lines, for example in plastic recycling applications.. Vibratory feeders can often be a viable alternative to screw feeders for difficult materials, where gentle vibratory feeding may allow feeding without build-up which can occur on screws and screw tubes.

Coperion at the K 2019: Hall 14, Stand 14B19

Continue Reading

Chemicals Fairs Food & Beverage Ingredients & Auxiliary Materials Mechanical & Thermal Processes Pharmaceuticals Plant Construction, Engineering & Components Valves, Pipes & Fittings

Filtech 2019
Visit the trade show for filtration and separation technology

Published

on

Picture: Filtech Exhibitions
Picture: Filtech Exhibitions

Filtration and separation techniques are among the most important basic procedural operations in all process industries. Most raw materials and products are mixtures of substances and must therefore be filtered or separated for further processing. Filter solutions play also an important role in achieving hygienic production environments, as required in the pharmaceutical and other process industries.

International Trade Show for Filtration and Separation

At the Filtech show, which takes place from 22 to 24 October 2019 in the Cologne trade fair, filter and separation solutions will take center stage. Due to this trade fair, Cologne will once again become the meeting point of the global filtration and separation industry with experts, users and suppliers from all relevant sectors. The organizer expects more than 400 exhibitors on 14,000 square meters of exhibition space. The Filtech Fair is the largest event in the world that focuses entirely on all aspects of filtration and separation

The exhibitors from all around the world will present the entire range of relevant products. Filter materials, media and auxiliaries such as textiles, cloths and mats, bags and tubes, metal mesh, glass fiber, activated carbon, paper and sieves form the basis. These are supplemented by filter elements, housings, plates, frames and other components. Users will also find manufacturers of complete filter systems for all media, as well as dryers and centrifuges. Machines for the production of filters complete the offer.

The Filtech trade show will take place this year from October 22 to 24, 2019, on the grounds of Koelnmesse in the district of Cologne-Deutz. The humble beginnings of the fair with 6,200 visitors in 2011 are now far behind. Last year, 14,000 people attended the event, more than half of whom came from abroad. The organizer Filtech Exhibitions expects that the number of visitors will increase again this year. The exhibition organizers are expecting more than 400 exhibitors this year and have significantly increased their exhibition space by expanding to the second level of Hall 11 of Koelnmesse.

In addition to the actual fair, Filtech offers a range of accompanying events. An extensive conference program will take place on all three days of the fair. For this program, the organizers were able to win prominent experts from academia and industry. In addition to top-class keynotes, workshops and lectures on a variety of relevant topics are offered.

The fair also offers one-day courses on selected topics. This year, short courses for solid / liquid separation and fine dust separation will be offered on October 31st.

Visitors of the fair can pre-register on the website of the fair. https://filtech.de/exhibition/visitor-registration . One-day tickets cost € 20.00, two-day tickets € 25.00, and one ticket for all three days € 30.00,
