High-precision diaphragm pumps for vaccine production



News, Pharmaceuticals, Pumps & Compressors

Since the start of the SARS-CoV-2 pandemic, numerous countries around the world have been researching new vaccines against the virus under high pressure. The Italian branch of a U.S. pharmaceutical company will also be involved in the mass production of the vaccine and is preparing for this. There must be no dosing errors or fluctuations when the substances used are conveyed. In addition, dosing must be very pure and without any contamination. To achieve this, the company needed high-precision, low-pulsation pumps that were hermetically sealed and certified to ATEX standards. At the same time, the time for manufacturing and delivering the pumps was very tight. For this, the inoculant producer turned to LEWA-Nikkiso Italy S.r.l., a subsidiary of the German LEWA GmbH based in Leonberg. The pump expert, experienced in international GMP standards, has been manufacturing special pumps for the pharmaceutical industry for over 25 years. Therefore, the hermetically sealed Ecodos model in the steam-cleanable and FDA-compliant version in LEF3 and LEG3 sizes with explosion protection was quickly found to be the right solution. Thanks to the combination of three pump heads each with a precisely controllable motor, particularly low-pulsation pumping is guaranteed. The pressure-stiff delivery characteristic of the pumps used ensures good reproducibility of the fluid quantities, especially in the critical, low capacity range below 30 percent.

Despite some successes in the fight against the Corona virus, research and the use of suitable inoculants are still a priority. To ensure that these can be produced reliably and in sufficient quantities, the appropriate technical equipment, such as hygienic and precise pumps, is required depending on the production method. The Italian branch of a US company is now planning and supporting the further mass production of an inoculant in conjunction with a major international pharmaceutical group and required the appropriate equipment for this. Specifically, organic active ingredients were to be gently and safely conveyed from a bioreactor together with carriers such as heptane and ethyl acetate for the further chromatographic purification process. The pumps used here had to be hermetically sealed and, on the other hand, ensure a constant and precisely adjustable flow rate. In addition, because of the use of solvents, an ATEX-compliant pump type was required. The total time for manufacturing and delivery of the units was also very tight, as the manufacturer wanted to start production of the vaccine as soon as possible.

In view of these high requirements, the company commissioned the Italian subsidiary of LEWA GmbH as a reliable cooperation partner. The pump expert has been active in the pharmaceutical industry for over 25 years and has extensive experience in GMP (Good Manufacturing Practice) production areas as well as in the special requirements of the U.S. Food and Drug Administration (FDA), which the pumps also had to meet. The agreed delivery date is mid-December 2020.


Pulsation-free pumping thanks to multi-head system


“When asked which pump type was best suited for this application, the decision was made in favor of the Ecodos model, which has been used successfully by leading pharmaceutical companies for many years. The hermetically sealed pump with quadruple PTFE sandwich diaphragm and diaphragm rupture monitoring is a guarantee for absolute pumping reliability, making it the first choice for inoculant producers.”

– Stefano Biolcati of LEWA-Nikkiso Italy S.r.l.


To meet the client’s request for a combination of different pumping capacities of 3600 l/h as well as 1500 l/h, LEWA’s team designed a set of two Ecodos pumps of class LEG3 and one pump of class LEF3. Since the active ingredients used also have to be pumped with as little pulsation as possible in order to avoid mixing errors, the pumps were designed in the triplex variant, i.e. with three pump heads per pump and motor. This design ensures that the pause intervals during metering remain very short with regard to longitudinal mixing. This made it possible to dispense with additional pulsation dampeners, which due to their design would have meant problematic dead spaces in terms of backmixing and cleaning.

“What now had to be taken into account was, on the one hand, that the aggregates transport sensitive active ingredients for further purification in the liquid chromatography process and, on the other hand, that the carriers heptane and ethyl acetate have solvent properties that require specific attention,” Biolcati explains. “Therefore, gentle and stable conveying had to be ensured even in the low capacity range.” Here, the Ecodos models offer good suction behavior with a small NPSHr value, so that cavitations do not occur even with carrier fluids with low viscosity, such as volatile solvents. In addition, the organic substances originating from the bioreactor are conveyed particularly gently, as the shear effect in the pumping process is very low. The inoculant is later obtained from these in the chromatography process step.


Wide adjustment range and high precision

“An additional requirement was the need for extremely precise metering over a wide capacity range,” Biolcati reports. “Especially with the Ecodos pumps, the flow rate can be kept constant here with a maximum deviation of +/- 1 percent using the controllable motors over the speed.” In combination with the pressure-stiff delivery characteristic, a precise and reproducible flow rate is guaranteed even with fluctuating back pressure. In this way, fluids are metered accurately to the milliliter and, moreover, conveyed in sufficient quantities for comprehensive production of inoculants. If an adjustment to the composition of the vaccine should become necessary at a later date, or if a larger volume of vaccine is simply to be provided, the required fluid quantities can be easily changed in this way.

Last but not least, the pumps had to enable a sterile manufacturing process and meet hygienic production requirements to rule out impurities or contamination of the fluids. Thanks to its compact design optimized for steam cleaning, the Ecodos variant also takes into account the difficult conditions in the GMP environment.


Delivery of the pumps in time for the start of production

Despite the special requirements placed on the pumps, LEWA was able to complete the order on time with delivery to the pharmaceutical company. “Thanks to the enormous commitment of the team and the efficient inclusion of individual standard components approved for the pharmaceutical industry, it was possible to achieve this ambitious goal,” Biolcati concludes. “We are very proud to have made this small contribution to the global fight against the pandemic.” Since January 2021, the new units have now been in successful operation without any failures.
