TDK Corporation (TSE 6762) announces the introduction of the EZA2500W-32048 TDK-Lambda brand bi-directional DC-DC converter model to its EZA series. The extended high voltage range now covers 260 to 400Vdc and the lower voltage 36 to 65Vdc. The operating temperature has been increased to -10 to +50°C. Double sided protective board coating and long-life dust resistant fans have also been included.
Designed for energy storage systems with rechargeable batteries, this 2500W digitally controlled, compact 1U power supply can seamlessly change conversion direction from high voltage dc sources, powered by solar or wind, to 48Vdc batteries and vice versa. Other applications include lithium-ion battery testing as well as the use of regenerated energy from robots, cranes, autonomous ground vehicles and lifts. The EZA2500 can be used to replace large power resistors currently used for lift braking and use that previously dissipated energy to charge batteries. That stored energy can be used to either provide peak power for high torque demands or as battery back-up for power cuts.
The output voltage and current can be programmed and monitored using the RS-485 communications port. Multiple units can be operated in parallel by using the RS-485 interface to set units for “droop mode” current share. Alarm signals are also accessible, as well as remote on/off and under/over voltage functionality. The high voltage (grid) to low voltage (battery) isolation is 3,000Vac, grid to ground 2,000Vac and battery to ground 500Vac.
The dimensions for the EZA2500 are 43.6mm (1U) high, 423mm wide and 400mm deep. All models in the EZA series are certified to the IEC/EN/UL 60950-1 and IEC/EN/UL 62368-1 safety standards with CE marking for the Low Voltage, EMC and RoHS Directives. A five-year warranty is standard.
Aalborg Energie Technik secures Order
Aalborg Energie Technik a/s (AET) will assist Novawood in achieving cleaner air and preventing soil contamination in addition to providing a commercial income from waste wood and railway sleepers, which were previously seen as a waste product.
By building a biomass-fired cogeneration plant, Novacarb aims to improve its environmental performance while maintaining its competiveness. In partnership with ENGIE Solutions a dedicated company has been created: Novawood.
The high-efficient cogeneration plant, Novawood, will produce steam for the Novacarb site in Laneuveville-devant-Nancy and power for the grid by combusting waste products. ENGIE Solutions will, as main contractor, arrange fuel collection from two sources: Railway sleepers from the French national railway company (SNCF) and waste wood from SOVEN.
The plant is in accordance with ENGIE Solutions’ strategy to support industries by providing them with solutions to the challenge of the energy transition. Their goal is to achieve: Optimised use of resources, increased supply and use of local, green energy as well as a more environmentally friendly production.
Novacarb is part of the Mineral Specialties division of the SEQENS group and specialises in the production and marketing of sodium carbonate and bicarbonate. Production has taken place for more than 160 years at this site and the products are made from two natural raw materials: Limestone extracted from its quarry in Pagny-sur-Meuse and salt from its Lénoncourt salt farms.
Novacarb’s goal with Novawood is to reduce the site’s dependence on the highly polluting coal by approx. 40% and reduce the CO2 emissions by 150,000 tonnes per year. With an investment of 80 mEUR, the biomass-fired cogeneration plant will supply steam for their production plant and it will also supply 115 GWh of green electricity per year to the national electricity network, corresponding to an annual consumption at around 65,000 households.
Energy will be produced from combusting two fuels: waste wood and railway sleepers. Waste wood, which is sourced through collection centres, consisting of e.g. scrapped furniture, floors, doors, windows and pallets and is handled by SOVEN. By combusting old railway sleepers a new business area is being created and the modernisation of the National Rail Network owned by SNCF can be made in an environmentally friendly way.
The fuel transformation is also an economic aspect for Novacarb, as the gradually increasing carbon tax price affects the competitiveness of the company. As a major local work place, it directly employs 300 people and 150 people from outside companies, who are permanently on site. Novacarb’s activity generates 900 local jobs, or a total employment pool of around 1,350 people. The Novawood project will help develop the region’s economy and attractiveness through the creation and sustainability of local jobs. The project will be a benchmark in terms of energy transition, circular economy and local job creation.
The Novawood project began in 2014 with talks between the parties (Novacarb, ENGIE Solutions and SNCF), followed by discussions at local and national levels. The operating authorisation was obtained in MAR 2018, and the project was announced as a winner of CRE 5 in DEC 2019.
The plant will annually combust around 130,000 tonnes of railway sleepers and waste wood, which would otherwise have been disposed of, and instead produce 55 tonnes steam/hour to Novacarb and 14,6 MWe of green electricity for export to the grid.
The railway sleepers contain creosote, PAH compounds and other chemicals from trains and are classified as hazardous waste. The creosote, which is tar containing phenolic compounds, can evaporate from the surface and/or be released into the soil. The waste wood in this case, includes Chromated Copper Arsenate treated wood, and therefore has, amongst other things, a high content of Copper. However, the combination of AET Combustion System, AET Biomass Boiler and flue gas cleaning ensures very low emissions, which comply with the European emission limits as a minimum. The plant is designed in accordance with WID.
The AET Biomass Boiler will be designed for a fuel heat input of 65 MWt, a boiler efficiency of 92% and a steam temperature of 522 oC, which ensure a high overall plant efficiency. To protect the boiler against corrosion it is equipped with Inconel cladding and special alloy steel for the superheaters.
AET is responsible for engineering, procurement and construction of the AET Biomass Boiler, including AET Combustion System, AET SNCR DeNOx System, boiler house, flue gas treatment, tail-end heat exchanger and PLC control system. The tail-end heat exchanger, which is positioned after the flue gas treatment, cools the flue gas temperature by more than 30 oC. The regenerated energy is, amongst other things, used at an ORC plant, which produces power. It thereby increases the overall plant efficiency further.
The in-house power consumption for the boiler plant is only approx. 1,6% of the fuel heat input and thereby increases the net power production.
The plant is planned to start power generation in the second half of 2022.
Alain Guillerme, Project Realization Director, Novawood: “As every industrial customer, NOVACARB requires a reliable steam supply and a high boiler availability. ENGIE has several AET Biomass Boilers in its portfolio, being operated for years. The experience from these sites is very good with low maintenance issues. In addition, the AET design offers high efficiencies, which is a critical criteria for an industrial plant operating all along the year. Lastly, the good experience we had with the AET project management has convinced ENGIE Solutions to sign with them for the Novawood project.”
“We are pleased to continue the cooperation with ENGIE Solutions and now with combustion of railway sleepers and waste wood; waste wood is an up-coming fuel in France. The high steam temperature, with combustion of railway sleepers and waste wood in this case, is essential to make a viable business case for ENGIE Solutions and Novacarb. At AET, we are very happy to take a new step with Novawood, which will reduce CO2 emissions by 150.000 tonnes per year”, says CEO of AET Lars Kristensen.
AET has previously supplied plants, which burns waste wood/railway sleepers in Germany, Austria and United Kingdom.
Regenerative storage power plant
ETW Energietechnik expands biogas plant
In Wehrbleck in Lower Saxony, the company ETW Energietechnik from Moers expanded an agricultural biogas plant into a regenerative storage power plant in 2019. The CHP experts were supported by the planning company Energethik from Osnabrück. In addition to the new Flex CHP with the TCG 2020 V20 biogas engine from MWM with 2 megawatts, electric and 2.3 megawatts, thermally, ETW also installed a combined gas storage tank with 8,490 and a heat storage tank with 1,000 cubic metres. The total investment amounts to 1.6 million euros.
Since 2001, farmer Andreas Rohlfs has been operating a biogas plant with an area of around 235 hectares. Based on the input materials maize, dung and liquid manure, the operator generated around 5.4 million kilowatt hours of electrical energy and 4.1 million kilowatt hours of thermal energy before the expansion. Since its expansion into a storage power plant, the plant now produces 5.7 million kilowatt hours of electrical energy and almost 5.8 million kilowatt hours of heat per year. The electricity is fed into the grid; the waste heat is fed into a district heating network for heating private and municipal buildings and is used to dry wood chips. Part of the heat is diverted to keep the engine warm when it is not running. This allows the direct marketer to quickly restart the engine if necessary and immediately access the full output of the CHP.
In addition to the increase in output, the plant now operates flexibly. In return, Rohlfs will earn an additional flexibility surcharge of 40 euros per kilowatt over the next five years. Afterwards, the farmer can optionally apply for a further ten-year EEG payment by means of a tender. His main advantage: thanks to the Flex CHP, his plant is now operated in such a way that electricity and heat can always be fed in at the most productive time of day. For this purpose, the biogas plant is controlled by a direct marketer in such a way that the storage tanks are always optimally filled when prices are at their highest and that the largest possible quantities of electricity and heat are available for this purpose.
The plant is powered by desulphurised biogas. For this purpose, the sulphur content is conditioned down from around 5,000 parts per million (ppm) to around 2 ppm. A safety alarm with integrated stop of the gas supply to the storage protects the CHP at a sulphur content above 2 ppm. This is particularly necessary because the sulphur content can rise faster in flex operation. After the preventive shutdown, operation of the engine is maintained with the gas from the storage tank.
„In order to be prepared for future NOx limits, ETW has already reserved the necessary space on the CHP container for an SCR catalytic converter. The plans also take into account a reserve for exhaust back pressure,“ explains Alexander Szabo, the responsible sales manager at ETW Energietechnik.
The variation of the substrate quantities also contributes to the flexibility of the CHP operation. This makes it possible to reduce biogas production at low electricity prices so that the CHP unit can be shut down for up to two days if necessary without overloading the gas storage tank. The heat storage tank can store 40,600 kilowatt hours of thermal energy and thus supply the heating network for around 50 hours without the CHP unit having to be put into operation. The bottom line is that the CO2 savings achieved by the regenerative storage power plant in electricity production can be estimated at 2,683 tonnes per year and in heat production, including process heat, at around 1,300 tonnes.
Two additional production halls
Expansion of capacities for the production of consumables
The Eppendorf Group is expanding its production capacity at the Oldenburg in Holstein site in Germany by building two additional production halls. As a result, Eppendorf Polymere GmbH, a wholly owned subsidiary of Eppendorf AG, will increase its total capacity by around 30 percent from 2021. A milestone for this targeted expansion was reached May 14, 2020 with the topping-out ceremony for the second hall currently under construction. The first hall has already been completed and will start production operations this month.
In Oldenburg, Eppendorf produces laboratory consumables made of high-quality plastic such as pipette tips and tubes, microtiter plates and single-use bioreactor vessels. Currently, these products are in particularly high demand from diagnostic laboratories and vaccine manufacturers around the world who are researching vaccines against the corona virus or carrying out Sars Cov-2 tests.
“We are registering a steady increase in demand for consumables from Eppendorf. The current global battle against the corona virus is just reinforcing this trend,” says Dr. Wilhelm Plüster, Chief Technology Officer at Eppendorf AG. “With the construction of the two new production halls we are responding to this trend, which has been continuing for years. In addition, sustainability was taken into account in the construction of the buildings.” continues Plüster. The two production halls will be heated and cooled by an existing combined heat and power plant. This will considerably reduce energy consumption.
